es18p
Elite 18” Powered Subwoofer
The ES18P active subwoofer continues the tradition of superior sound, performance, and reliability established by the classic Yorkville LS801P. This next-generation update offers even more power and earth-moving bass projection from a custom-engineered 18-inch speaker.
The car-friendly enclosure was meticulously designed for sound and mobility, and is over 30% lighter than the 21-inch ES21P while preserving the series’ signature punch. Tilt-back wheels and top/bottom/side bar handles improve maneuverability and stacking.
Suitable for touring or fixed installations, the cabinets are constructed of 15 mm 11-ply Baltic birch, with rugged internal bracing to reduce resonance and increase durability, and finished with anti-resonant metal grilles.
With 3200 watts of peak power, proprietary DSP-based limiters, three DSP-based voicing options, link ports to easily connect multiple ES Series speakers, and Bluetooth® control using the free companion app, the ES18P blends classic performance, modern convenience, and uncompromising sound.
Features
- 3200 W Peak Power (1600 W Program)
- Custom-Designed 18” Woofer with 4” Voice Coil
- Proprietary DSP-Based Limiters
- 3 DSP-Based Voicing Modes (Punchy, Smooth, Deep)
- iOS and Android App for Added Subwoofer Control
- Made in Canada
Specifications
| System Type | Rear Horn Loaded Powered Subwoofer |
| Power Rating | 3200 W Peak (1600 Watts Program) |
| Max SPL | 140 dB Peak (134 dB Continuous) |
| Frequency Response (Hz +/- 3dB) | 43 Hz – 150 Hz |
| Driver Configuration | 18″ |
| LF Driver(s) | 18″ Cast Frame Woofer with 4″ Voice Coil |
| Outputs | 1x 1/4″ Link Output, 1x XLR Link Output |
| Inputs – 1/4 IN Jacks | 1x Link Input |
| Inputs – XLR | 1x XLR Input, 1x XLR Mono Blend Input |
| Level Controls | Master – Sub Level |
| LED Indicators | Power, Activity, Protection (Clip, X-Max, Temp) |
| Other Controls / Features | Mode Control (Punchy, Smooth, Deep), High Frequency Rolloff (10 Hz Steps from 80 Hz to 150 Hz |
| Wheels | 2 (Rear Tilt-back) |
| Bar Handles | 6 (2 Top Rear Edge, 2 Bottom, 1 Left Side, 1 Right Side) |
| Pole Mount Adapter (1 3/8 | 1 (Top) |
| Enclosure Materials | 15 mm (5/8″) 11-ply Russian Birch |
| Grille | Perforated Metal |
| Covering / Finish | Black Ultrathane Paint |
| Dimensions (DWH) | 24″ x 22.8″ x 34.7″ (61 cm x 58 cm x 88 cm) |
| Weight | 137 lbs / 62 kg |
